Mimaki Tx330 Series – Next-Gen Hybrid Textile Printing

The Mimaki Tx330 Series is a high-performance hybrid textile printer, designed for direct-to-fabric and dye sublimation printing. Featuring waterless technology, advanced ink systems, and scalable production capabilities, the Tx330 Series delivers vibrant, eco-friendly prints with unmatched efficiency.

TX330-1800

Hybrid textile inkjet printer with the ability to print on both fabric and paper. Options for two ink sets and the ability to easily switch the printing mechanism to accommodate direct fabric or transfer paper printing enables the production of soft-signage and short run interior fabrics.

TX330-1800B

Similar to the Tx330-1800 but with the addition of a space-saving belt conveyor system to stably print on stretchy, thick, and thin fabrics commonly used for apparel. It supports short run, variable apparel production in limited space such as design offices, schools, and fabric retail stores.

Key Features & Benefits

Hybrid Printing Technology – Prints on both fabric and sublimation paper, offering maximum versatility.
Eco-Friendly Waterless Printing – Eliminates pre-treatment, steaming, and washing, reducing water consumption and environmental impact.
High-Speed Production – Prints 25% faster than previous models, ensuring efficient textile manufacturing.
Precision Color Management – Mimaki’s TP410 pigment ink expands the color gamut, including a new green special color.
Automatic Maintenance Features – Nozzle recovery and belt washing systems minimize downtime and improve print stability.

Why Choose the Mimaki Tx330 Series?

Fashion & Sportswear – High-resolution custom apparel, jerseys, and accessories.
Soft Signage & Banners – Durable fabric-based promotional graphics.
Home Décor & Interior Fabrics – Stunning curtains, upholstery, and wall coverings.

Questions About the
Tx330 Series?

Our product specialists are ready to help you find the best. solution.

We are available Monday to Friday from 8 a.m. to 5 p.m. CST.

Contact Us

Application Examples

Schedule a Demo

TX330 Series Inks & Resource Documentation

Specifications

Printhead

Print Resolutions

Print Speed (4 color mode)

Maximum Print Width

Maximum Media Thickness

Maximum Media Weight

Ink Type

Power Supply

Dimensions (W x D x H)

Weight (uncrated)

On-demand 330 Series piezo head (2 staggered layout)

300, 600, 900, 1200, 1800 dpi

646 sq/ft per hr (60 sq/m per hr)

Fabric: 75.2″ (1,910mm)
Paper: 76.4″ (1,940 mm)

0.2″ or less (5.0mm)

88.2 lb or less (40kg)

Textile Pigment Ink TP410 (2L)
C/M/Y/K/R/Gr/Bl/Lk

Sublimation Dye Ink Sb420 (2L)
Bl/M/Y/K/Lb/Lm

At Hybrid Ink Set TP410 (2L)
C/M/Y/K

AC100~120V/200~240V±10% 3A 50/60Hz±1Hz

127.2″ x 38.0″ x 73.1″ (3,230 mm x 965 mm x 1,857 mm)

641.5 lb (291kg)

Textile Pigment Ink

(TP410)

2L

Cyan

TP410-C-2L

Magenta

TP410-M-2L

Yellow

TP410-Y-2L

Black

TP410-K-2L

Red

TP410-R-2L

(TP410)

2L

Green

TP410-G-2L

Blue

TP410-BL-2L

Light Black

TP410-LK-2L

Sublimation Dye Ink

(SB420)

2L

Blue

TP420-BL-2L

Magenta

TP420-M-2L

Yellow

TP420-Y-2L

Black

TP420-K-2L

Light Blue

TP420-LB-2L

(SB420)

2L

Light Magenta

TP420-LM-2L

At Hybrid Ink Set

(TP410)

2L

Cyan

TP410-C-2L

Magenta

TP410-M-2L

Yellow

TP410-Y-2L

Black

TP410-K-2L

Technical Details

TX330 Series Spec Sheet

Brochures

TX330 Series

Why Choose the Mimaki TX330 Series?

The Mimaki TX330 Series is a next-generation hybrid textile printing platform engineered to deliver exceptional versatility, sustainability, and image quality across a wide range of fabric applications. Designed for both direct-to-fabric and sublimation transfer workflows, it offers a unified solution for businesses engaged in fashion, sportswear, soft signage, and interior décor.
Built on Mimaki’s flagship 330 print engine, the TX330 Series supports both textile pigment and dye-sublimation inksets, which can be loaded separately or simultaneously. This dual-ink capability enables printing on natural and synthetic fabrics as well as transfer paper, significantly expanding application flexibility. The TX330-1800 model accommodates both fabric and paper, while the TX330-1800B variant features a belt-driven transport system for stable printing on stretchy or thick textiles.
The TX330 Series employs a waterless printing process, eliminating the need for pre-treatment, steaming, and washing. This not only reduces environmental impact but also simplifies production and lowers operational costs—making it particularly well-suited for space-constrained or sustainability-focused operations.
Mimaki’s core technologies—including Waveform Control, Variable Dot Technology, Mimaki Advanced Pass System (MAPS), Nozzle Recovery System, and Mimaki Intelligent Heaters—ensure consistent high-resolution output and minimal downtime. The use of TP410 pigment inks, featuring an expanded color gamut with options such as green and light black, further enhances color vibrancy and accuracy. All inks are bluesign® approved and OEKO-TEX® ECO PASSPORT certified, ensuring compliance with global safety and sustainability standards.
In summary, the Mimaki TX330 Series offers a robust, eco-conscious, and highly adaptable textile printing solution. Its hybrid architecture, advanced automation, and certified ink systems make it a strategic investment for businesses seeking to streamline operations while expanding their creative and commercial capabilities.
